Machine type
Main specifications

MC-275

MC-315

MC-350

MC-425

Cutting angle

90°

45°

90°

45°

90°

45°

90°

45°

◎

Φ80

Φ60

Φ100

Φ90

Φ100

Φ90

Φ100

Φ90

☐

75*75mm

50*50mm

90*90mm

80*80mm

100*100mm

90*90mm

125*125mm

110*110mm

L

75*75mm

50*50mm

90*80mm

90*60mm

100*100mm

90*90mm

125*125mm

110*110mm

▭

75*75mm

50*50mm

90*80mm

90*60mm

100*100mm

90*90mm

130*80mm

130*80mm

●

25mm

25mm

30mm

30mm

50mm

50mm

55mm

55mm

█

25mm

25mm

30mm

30mm

45mm

45mm

50mm

50mm

Motor power

2.0/2.4KW

2.4/3.0KW

2/4level 3.3/4KW

2/4level 3.3/4KW

Spindle speed

96/48RPM 48/24RPM

84/42RPM 42/21RPM

84/42RPM 70/40RPM

84/42RPM 120/6ORPM

Suitable saw blades

HSS BLADE diameter

HSS BLADE diameter

HSS BLADE diameter

HSS BLADE diameter

Cooling System

250/275

250/275/300/315

275/300/315/350

300/315/350/425

Air Compression

PV type/AC type

PV type/AC type

0.4-0.6Mpa

0.4-0.6Mpa

Model

BR-F315-NC1
BR-F315-NC2

BR-F350-NC1
BR-F350-NC2

BR-F400-NC1
BR-F400-NC2

BR-F350-NC2-A(Cutting angle)
BR-F350-NC3-A(Can cut any angle)

Turning angle of head

90°

0-90°

Processable material

lron, stainless steel, copper, aluminum, plastic tubes

Circle tube

<=85mm

<=100mm

<=130mm

<=80mm

Square Tube

<=70*70mm

<=90*90mm

<=120*120mm

<=70*70mm

Sawing capacity

Solid circle bar

/

<=70mm

/

Solid square bar

/

<=60*60

<=80*80

/

Cooling Lubrication

Water-soluble cutting oil

Main motor

2/2.4KW

4KW

4.5/5.5KW

4.5/5.5KW

Spindle speed

Automatic arbitrary frequency conversion speed control 60-35ORPM

Feeding method

Servo feeding, hydraulic tool feeding

Parameter

Driving method

Servo Motor1.5KW +Precision Reducer

Clamp

Automatic double-opening and double-closing of clamps(Zero Scratch)

Max single feeding stroke

5-1500Single(CNC automatic calculation of unlimited length, multiple feeding)

Cut length setting

5-5000mm

Accuracy

±0.05-0.15mm

Shortest tailstock

0.10mm

Width

600-1600mm

Feeding rack

Placeable material length

3000-10000mm(Can be customized according to customer requirements)

Loadable weight

3000-500OKG

Operating Interface

Human-machine contact section (easy to program)

Electric control

Control System

Servo system + integrated board + PLC

Power

415/380V/220/24V

Module Option

415/380V/220/24V
