20+ years of focusing on pipe profile shaping
Providing One-Stop Integrated Solution Service
MC-425 CNC Pipe Bending
|
Item |
Name |
Unit |
Data |
Remark |
|
|
1 |
motor power |
KW |
4 |
|
|
|
2 |
Saw blade size |
mm |
max 450X3.0 |
|
|
|
3 |
Cutting ability |
◎ |
mm |
Φ120 |
|
|
4 |
voltage |
V |
380 |
customizable |
|
|
5 |
Feeding accuracy |
mm |
±0.1 |
|
|
|
6 |
cutting accuracy |
mm |
±0.1 |
|
|
|
7 |
Accuracy of tail pulling |
mm |
±0.1 |
|
|
|
8 |
Length of single feed |
mm |
1000 |
customizable |
|
|
9 |
oil pump motor |
KW |
2.2 |
|
|
|
10 |
Servo motor power |
KW |
1 |
|
|
|
11 |
Oil pump discharge capacity |
L |
20 |
|
|
|
12 |
clamp opening |
mm |
150 |
|
|
|
13 |
rated working pressure |
mpa |
7 |
|
|
|
14 |
machine weight |
KG |
1500 |
|
|
|
15 |
The transmission structure |
|
Gear, four axis rotation |
||
CONTACT US
Contact US
Product Information
Quantity
Unit
Piece
Support order samples, customization, wholesale direct, and complete payment. If the product you look for does not have corresponding customized content, pls fill out the form below to contact us, and we will reply ASAP.
