20+ years of focusing on pipe profile shaping
Providing One-Stop Integrated Solution Service
425 CNC Pipe Bending
|
Machine model |
MC-425CNC |
Note |
|
|
Maximum cutting capacity |
◎ |
Φ120mm |
|
|
|
□ |
110 mm×110mm |
|
|
|
● |
55mm |
|
|
|
■ |
50×50mm |
|
|
Main motor power |
3.3/4Kw |
|
|
|
Oil pump motor power |
2.2 Kw |
|
|
|
Servo motor power |
1 Kw |
|
|
|
Spindle speed |
60-120 |
|
|
|
Applicable saw blades |
external diameter |
Φ250-450mm |
|
|
|
centre hole |
Φ32mm |
|
|
|
pinhole |
2XΦ11X65mmPCD |
|
|
Oil pump system |
4-stage motor, duplex pump, working pressure 25-50kg/cm². |
||
|
Feed stroke |
1500mm×several times |
Customised |
|
|
Feeding accuracy |
±0.15 |
|
|
|
Cutting precision |
±0.15 |
|
|
|
Drawing accuracy |
±0.15 |
|
|
|
cooling system |
90W motor，Automatic Cooling Circulation |
|
|
|
Machine weight |
1500kg |
||
