Machine type
Main speifications

DW-18CNCx3A-1S

DW-25CNCx2A-1S
DW-25CNCx3A-1S

DW-38CNCx2A-1S
DW-38CNCx3A-1S

DW-50CNCx2A-1S
DW-50CNCx3A-1S

DW-63CNCx2A-1S
DW-63CNCx3A-1S

Max bending pipe

 diameter ×

 thickness

Φ18mm×1.6mm

Φ25mm×1.6mm

Φ38mm×2mm

Φ50mm×3mm

Φ63mm×3mm

Max. bending radius

R80mm

R100mm

R200mm

R250mm

R280mm

Min. bending radius

R5mm

R5mm

R15mm

R20mm

R25mm

Max. bending angle

190°

190°

190°

190°

Feeding method

2500mm

2500mm

2500mm

3000mm

3000mm

Feeding method

Direct feeding

Clamping feeding

Working speed

Bending speed

Max200° /s

Max200° /s

Max200° /s

Max85° /s

Max85° /s

Rotary speed

Max2000° /s

Max200° /s

Max200° /s

Max200° /s

Max200° /s

Feeding speed

Max1000mm/s

Max1000mm/s

Max1000mm/s

Max1000mm/s

Max1000mm/s

Accuracy

Bending accuracy

±0.1°

±0.1°

±0.1°

±0.1°

±0.1°

Rotary accuracy

±0.1°

±0.1°

±0.1°

±0.1°

±0.1°

Feeding accuracy

±0.1mm

±0.1mm

±0.1mm

±0.1mm

±0.1mm

Data entry method

1.axis(XYZ)

2.Woking value(YBC)

Bending method

1.Servo Bending:

1KW(3 axis)

1.Servo Bending:

1KW(3 axis)

2.Hydraulic Bending

1.Servo Bending:

1KW(3 axis)

2.Hydraulic Bending

1.Servo Bending:

5KW(3 axis)

2.Hydraulic

Bending

1.Servo Bending:

  7KW(3 axis)
2.Hydraulic

Bending

Power of rotary servo motor

400W

400W

400W

750W

750W

Power of feeding servo motor

750W

750W

1KW

1KW

1KW

Max bending groups

12PCS/3PCS

Max storing components

330sets/125sets

Motor power

Pneumatic type

3KW

4KW

5.5KW

5.5KW

Max Oil pressure

10Mpa

12Mpa

12Mpa

12Mpa

12Mpa

Machine weight

800KG

1000KG

1500KG

2500KG

3000KG

Machine size

2760x690x1000mm
3m

3000x760x1100mm

3830x760x1200mm
4

4900x1300x1300mm

4900x1300x1300mm

Machine type
Main speifications

DW-75CNC×2A-1S
DW-75CNC×3A-1S

DW-89CNCx2A-1S
DW-89CNCx3A-1S

DW-100CNCx2A-1S
DW-100CNCx3A-1S

DW-115CNCx2A-1S
DW-115CNCx3A-1S

Max bending pipe

diameter x thickness

Φ75mm
×
4mm

Φ89mm
×
6mm

Φ100mmx8mm

Φ115mmx10mm

Max. bending

radius

R350mm

R350mm

R450mm

R450mm

Min. bending

radius

R30mm

R30mm

R50mm

R50mm

Max. bending

angle

190°

190°

190°

190°

Feeding method

3000mm

4200mm

4200mm

4200mm

Feeding method

Direct feeding

Clamping feeding

Working speed

Bending speed

Max40° /s

Max30° /s

Max30° /s

Max30° /s

Rotary speed

Max160° /s

Max160° /s

Max160° /s

Max160° /s

Feeding speed

Max800mm/s

Max800mm/s

Max800mm/s

Max800mm/s

Accuracy
Feeding accuracy

Bending accuracy

±0.1°

±0.1°

±0.1°

±0.15°

Rotary accuracy

±0.1°

±0.1°

±0.1°

±0.1°

Feeding accuracy

±0.1mm

±0.1mm

±0.1mm

±0.1mm

Data entry method

1.axis(XYZ)

2.Woking value(YBC)

Bending method

1.Servo Bending:

7KW(3 axis)

1.Servo Bending:

11KW(3 axis)
2.Hydraulic Bending

1.Servo Bending:

15KW(3 axis)
2.Hydraulic Bending

1.Hydraulic Bending

Power of rotary

servo motor

1KW

1.5KW

1.5KW

2KW

Power of feeding

servo motor

1.5KW

2KW

3.5KW

3.5KW

Max bending groups

16PCS/33PCS

Max storing components

330sets/125sets

Motor power

7.5KW

11KW

15KW

22KW

Max Oil pressure

12Mpa

14Mpa

14Mpa

14Mpa

Machine weight

4500KG

5500KG

6000KG

7000KG

Machine size

4950x1350 x1230mm

5090x1350x1230mm

5090x1350x1230mm

5090x1350x1230mm
