Home  >  Shop  >  Pipe Bending  >  CNC Pipe Bending  >  DW89CNCX2A-1S
description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Description

Serial number

Name

Unit

Parameter

Remarks

1

Maximum bending diameter

mm

Φ89×8t



2

Maximum bending radius

mm

250

Can be based on customer requirements

3

Minimum bending radius

mm

According to pipe diameter



5

Maximum feeding length

mm

3500

Can be based on customer requirements

6

Feeding method



1.Direct delivery
2.Delivery



7

Maximum bending angle

Degree

190



8

Use the controller



PLC+tablet



9

The number of bends that can be set for each pipe fitting

indivual

45



10

Speed ​​of work



Bending speed

Deg/sec

30

Adjustable





Tube transfer speed

Deg/sec

160

Adjustable





Feeding speed

Mm/sec

800

Adjustable

11

Accuracy

Feeding accuracy

mm

±0.1







Tube rotation accuracy

Degree

±0.1







Bending accuracy

Degree

±0.15



12

Rotary tube servo motor power

Kw

1.5

Mitsubishi

13

Feeding servo motor power

Kw

2

Mitsubishi

14

Data input method



1. Coordinate values (X, Y, Z)
2. Working value (Y, B, C)



15

Hydraulic motor horsepower

Kw

11



16

greatest pressure

MPa

14

Adjustable

17

Hydraulic system control



Solenoid directional valve

Yuken

18

Fuel tank capacity

L

350



19

Machine weight

Kg

5500



20

Machine size

cm

5650×1350×1360
